SDG Generator
Standard digital generator with process settings for production stations.
The SDG adds production process control to Rinco's digital generator platform: weld-relevant settings, monitoring and I/O for stations and machines, with automatic frequency tracking and consistent amplitude regulation at its core.
- Operating frequency
- 70 kHz / 40 kHz / 35 kHz / 30 kHz / 20 kHz
- Maximum power output
- SDG70: 100 W; SDG40: 400/800 W; SDG35: 400/750 W; SDG35-4: 200/400/750/900 W; SDG30: 500/1000 W; SDG20: 1000/1500/2000 W
- Power supply
- 230 V, 50/60 Hz (± 10%)
- Operating modes
- Time mode, Energy mode, Time and Energy mode, Time or Energy mode, Continuous mode, Contact cut-off mode
- Data input
- Cursor keys / RS485 / CANopen
- Visualisation
- 5 x 20 character LCD
Defining features
- Interactively programmable
- Multirack for similtanious operation of several modules - optional
- Softstart function
- Softstop function
- Made in Switzerland
Technical specifications
| Operating frequency | 70 kHz / 40 kHz / 35 kHz / 30 kHz / 20 kHz |
|---|---|
| Maximum power output | SDG70: 100 W; SDG40: 400/800 W; SDG35: 400/750 W; SDG35-4: 200/400/750/900 W; SDG30: 500/1000 W; SDG20: 1000/1500/2000 W |
| Power supply | 230 V, 50/60 Hz (± 10%) |
| Operating modes | Time mode, Energy mode, Time and Energy mode, Time or Energy mode, Continuous mode, Contact cut-off mode |
| Data input | Cursor keys / RS485 / CANopen |
| Visualisation | 5 x 20 character LCD |
| Amplitude | Adjustable 15–100%, changeable in 1% increments |
| Dimensions WxHxD | 150 x 285 x 430 mm, without connector |
| Weight | 9.5 kg |
