Description
Ultrasonic Generator model Eco Line
The Ecoline generator is the ideal solution for small budgets. Its compact design and how easy it is use mean that the generator can be used for manual workstations in a wide range of sectors. The Ecoline generator is available as a set or kit with an ultrasonic hand-held unit and is supplied in a practical carry case.
Ecoline sets
Ecoline HG 35:
Hand gun HG35 with Ecoline generator for welding thermoplastic parts
Ecoline HW 35:
Hand welder HW35 with Ecoline generator for welding thermoplastic parts
Ecoline HC 35:
Hand cutter HC35 with Ecoline generator for cutting textiles and non-woven materials
Ecoline HT 35:
Hand tacker HT35-3 with Ecoline generator for welding textiles, non-woven materials and thermoplastic parts
Defining Features:
- Small and handy
- Strong and light weight
- Plug and play
- Adjustable amplitude
- Handle for easy transport
- Digital ultrasonic technology
- Delivered in a plastic case
- Includes tools for service
- Made in Switzerland
Technical Specifications:
- Operating frequency: 35 kHz
- Max. power output: 480 W
- Operating mode: Continuous
- Buttons: Test button, release button
- Amplitude: Adjustable from 40% to 100%, changeable in steps of 10%
- Weight of generator: 3.4 kg
- Compatible with Hand Welding & cutting units – Hand cutter HG35-4, Hand welder HW35-4, Hand cutter HC35-5, Hand tacker HT35-3
Documents
Brochure Eco Line Generator and Hand Set Kits
