35 kHz01 / 01Click to expand ⤢Ultrasonic actuator · Special Actuators
MA 35
Compact 35 kHz actuator module for space-constrained machine integration.
The MA 35 is a compact 35 kHz actuator for machine builders who need ultrasonic welding capability in a tight envelope. Simple mounting and dependable actuation make it a straightforward integration into special machines and multi-station tooling.
- Operating frequency
- 35 kHz
- Application
- The MA35-20 is only suitable for axial loads
- This actuator is used as a component in a special purpose machine
- Maximum force
- 450 N at 6 bar compressed air
- Maximum stroke
- 20 mm
- Weight
- 1.7 kg including transducer
Defining features
- Can be configured with RDG, SDG, AGM and ADG generators as well as with an external controller
- Designed for integration into special purpose machines
- Very small and compact
- Adjustable stroke limitation
Technical specifications
| Operating frequency | 35 kHz |
|---|---|
| Application | The MA35-20 is only suitable for axial loads |
| This actuator is used as a component in a special purpose machine | |
| Maximum force | 450 N at 6 bar compressed air |
| Maximum stroke | 20 mm |
| Weight | 1.7 kg including transducer |
| Generator suitability | SDG35-400/750, RDG35-400/750, AGM35-400/600, ADG35-400/600 |
