35 kHz01 / 01Click to expand ⤢Ultrasonic actuator · Special Actuators
SPC 35
Pneumatic 35 kHz actuator for precise automated welding stations.
The SPC 35 delivers precise 35 kHz welding in automated stations: controlled pneumatic actuation for smaller parts and finer joints, packaged for straightforward mounting into special machines and rotary systems.
- Operating frequency
- 35 kHz
- This converter is used as a component in special purpose machines
- Mounting
- At threaded spindle M30 x 1.5 with two counternuts
- Compression stroke
- 8 mm
- Weight
- 1.5 kg
- Generator suitablility
- SDG35-400/750, RDG35-400/750, AGM35-400/600, ADG35-400/600
Defining features
- Suitable for automated welding operations with short cycles
- Ideally suitable as a replacement for composite horns
- Constant spring load
- Heavy duty
Technical specifications
| Operating frequency | 35 kHz |
|---|---|
| This converter is used as a component in special purpose machines | |
| Mounting | At threaded spindle M30 x 1.5 with two counternuts |
| Compression stroke | 8 mm |
| Weight | 1.5 kg |
| Generator suitablility | SDG35-400/750, RDG35-400/750, AGM35-400/600, ADG35-400/600 |
